VIVIX-S 4343FW

FINEST Image Quality

  • Pixel size: 99㎛
  • High DQE
  • Semi-dynamic function
  • Image enhancement with photon-understanding AI solution



FINEST Durability

  • Unbreakable glass-free TFT
  • Robust design: drop height of 1.5m
  • IP67 water and dust resistance



FINEST Usability

  • Lighter weight
  • Long lasting battery: up to 16 hours (2 batteries)
  • Convenient charging methods
  • User-friendly functions
Technical Specifications
Model NameFXRD-4343FAW
Technologya-Si Flexible TFT
ScintillatorFlexible Csl
Pixel Pitch99 ㎛
Spatial Resolution5.0 lp/㎜
Pixel Matrix4316 x 4316 pixels
Image Size43 ㎝ × 43 ㎝
Grayscale16 bits
Image Acquisition Time≤ 4.5 s
Recommended Cycle Time7 s
Data InterfaceGigabit Ethernet / IEEE 802.11n / ac
X-ray Generator InterfaceDR trigger Mode / AED Mode /  Software Trigger
Dimensions46.0 ㎝ × 46.0 ㎝ × 1.5 ㎝
Weight2.95 kg (1 battery)  / 3.15 kg (2 batteries)
BatteryLithium Ion 3400mAh x 2 / 16 h (standby) * 3,000 images at a 15-second cycle.
Dust and Water ResistantIP67
X-ray Voltage Range40 - 150 kVp
Operating Environment0°C to 40°C / 5 % to 90 % RH (non-condensing)
Power ConsumptionNormal: Max. 24 W / Charging: Max. 80W
